2012 Specialized Source Eleven
- Serial
- WSBC602278035G
- Manufacturer
- Specialized
- Model
- Source Eleven
- Year
- 2012
- Primary colors
- Silver, gray or bare metal
- Frame size
- XL
- Wheel diameter
- 700 C
- Tire width
- Wide tire
- Distinguishing features
-
Specialized E5 aluminum, fully manipulated tubing, smooth weld, compact design, internal cable routing, integrated headset, fender/rack eyelets, center kickstand plate, eccentric BB adjuster BikeSwift E-Bike conversion, front hub motor, handlebar-mounted controller, rack-mounted battery.
Frame and fork
- Fork
- Aluminum legs/crown, Cr-Mo steerer, 52mm fully integrated headset, fender/rack eyelets, internal light cable routing
- Headset
- 1-1/8" sealed Cr-Mo Campy Style integrated bearings, 15mm alloy cone spacer with 30mm of spacers
Wheels
- Front Rim
- DRX300 Disc, alloy double-wall, sleeved, CNC machined, 32h
- Rear Rim
- DRX300 Disc, alloy double-wall, sleeved, CNC machined, 32h
- Front Hub
- Bafang G311 250 watt (600 watt peak) planetary geared brushless DC hub motor
- Rear Hub
- Shimano Alfine 11, 32h
- Spokes
- Stainless, 2mm
- Front Tire
- Specialized Espoir Sport Reflect w/ double BlackBelt, 60 TPI, wire bead, 700x30c
- Rear Tire
- Specialized Espoir Sport Reflect w/ double BlackBelt, 60 TPI, wire bead, 700x30c
- Front Tube
- Presta Valve
- Rear Tube
- Presta Valve
Drivetrain and brakes
- Front Brake
- Shimano Alfine BR-S501 hydraulic disc, dual-piston, 160mm SM RT 61 rotor
- Rear Brake
- Shimano Alfine BR-S501 hydraulic disc, dual piston, 160mm SM RT 61 rotor
- Front Brake Lever
- Shimano Alfine BL-S500 hydraulic 3-finger alloy lever
- Rear Brake Lever
- Shimano Alfine BL-S500 hydraulic 3-finger alloy lever
- Front Shifter
- Shimano Alfine 11 Rapidfire
- Rear Shifter
- Shimano Alfine 11 Rapidfire
- Cog/Cassette/Freewheel
- Gates Centerline Track sprocket, 24t, lock ring
- Chain
- Gates Centertrack belt
- Crankset
- Single ring, forged, 130BCD, 170mm length, w/o chainring
- Chainrings
- 55T Gates Centertrack belt drive chainring
- Bottom Bracket
- GXP, external bearing
- Pedals
- Shimano A530 Sport/Touring Road Pedals
- Ebike Battery
- Weatherproof, locking enclosure 37V 13 amp-hour frame mount (Hailong) with LG 2.6 Ah M26 cells (10S 5P cell configuration). 6.5 lbs.
Additional parts
- Stem
- Specialized EliteSet, 3D forged alloy, 12-degree, 4-position adjustable, 4-bolt, 31.8mm clamp
- Grips/Tape
- Ergon BioKork grips
- Handlebar
- Specialized DB, butted alloy, flat bar, 6-degree bend, 31.8mm
- Saddle
- Velo Orange black leather saddle SA-0015-BLK
- Seatpost
- Alloy, 2-bolt forged head, 27.2mm, 350mm
- Seatpost Clamp
- 31.8 clamp ID, superlight forged and machined alloy
- Front Lights
- Supernova E3 Pure w/ multimount, black anodized
- Rear Lights
- Supernova E3 Tail Light
- Kickstand
- Pletscher Optima, Center kick stand
- Rack
- Racktime Ultra, Specialized custom, hollow alloy, max. load 10kg
- Front Fender
- Specialized aluminum, anodized finish, aluminum struts, "hidden" rack mount bracket
- Rear Fender
- Specialized aluminum, anodized finish, aluminum struts, "hidden" rack mount bracket
- Bell/Noisemaker
- Black bell
