2015 Trek 3500
- Serial
-
WTU108C0420J - Manufacturer
- Trek
- Model
- 3500
- Year
- 2015
- Primary colors
- Green
- Frame Material
- Aluminum
- Wheel diameter
- 26in
- Tire width
- Wide tire
- Distinguishing features
-
Alpha Silver Aluminum, w/disc compatible dropouts, replaceable derailleur hanger
Frame and fork
- Fork
- SR Suntour M-3030 w/coil spring, preload, 75mm travel
- Headset
- 1-1/8" threadless
Wheels
- Rear Tire
- Bontrager LT3, 26x2.0"
- Front Tire
- Bontrager LT3, 26x2.0"
- Rear Wheel
- Formula FM21 alloy front hub; Formula FM31 alloy rear hub w/Bontrager AT-550 36-hole rims
- Front Wheel
- Formula FM21 alloy front hub; Formula FM31 alloy rear hub w/Bontrager AT-550 36-hole rims
Drivetrain and brakes
- Cog/Cassette/Freewheel
- Shimano TZ31 14-34, 7 speed
- Crankset
- Shimano M131, 48/38/28 w/chainguard
- Rear Derailleur
- Shimano Tourney TX35
- Front Derailleur
- Shimano Tourney
- Rear Shifter
- Shimano Altus EF51, 7 speed
- Front Shifter
- Shimano Altus EF51, 7 speed
- Rear Brake
- Tektro alloy linear-pull brakes w/Shimano Altus levers
- Front Brake
- Tektro alloy linear-pull brakes w/Shimano Altus levers
- Pedals
- Wellgo nylon platform
Additional parts
- Grips/Tape
- Bontrager SSR
- Stem
- Bontrager Forged, 25.4mm, 25 degree
- Handlebar
- Bontrager Riser, 25.4mm, 30mm rise
- Seatpost
- Bontrager SSR, 31.6mm, 12mm offset
- Saddle
- Bontrager SSR
