Battery #: RP1304AA1A100975
Battery: 48V, 15Ah (672Wh) with Lithium NMC Samsung 35E cells, rated for 800 charge cycles
Charger: 48V, 2 Amp, operates on 100V-240V AC power outlets
Controller: 48V, 750W
Display: 5V 1 Amp
Hub Motor: 750W brushless Shengyi direct drive hub motor with regenerative braking
Shifter: Shimano SL-TX50-7R thumb shifter, 7-speed
Spokes: 12-gauge stainless steel
Stem: Zoom, 60-degree angle adjustment, 100mm length, 88mm height adjustment
Rear Rack: Integrated, 60lb carrying capacity, 16mm tubing diameter
Tires: Kendra K-Rad 26” x 2.3” K-Shield puncture-resistant liner
Max Tire Width: 2.3”
Rims: Weinmann Goliath, alloy, double wall, 36H
Saddle: Velo Plush with lifting handle
Seatpost: 340mm x 27.2mm (diameter is 27.2mm)
Seat Tube Length: 14.5”
Seat Height: 24.5” - 33” (measured from bottom of the pedal stroke)
Grips: Durable Imitation Leather, ergonomic
Handlebar: Custom formed aluminum
Handlebar Width: 600mm (24”)
Handlebar Height: 42” - 45” (adjustable)
Handlebar Reach: 13.5”
Headset: Semi-integrated, 1-⅛” straight steerer tube
Top Tube Length: N/A
Headtube: 7”
Pedals: Forged aluminum platform with reflectors, standard 9/16” x 20 TPI threading
Fenders: Black plastic front and rear for full coverage
Fork: Spring fork, 100mm travel, with lockout and preload adjustment
Frame: 6061 Aluminum
Frame Size: 14”
Freewheel: 7-speed freewheel, 11-34T
Gearing: 1 x 7-speed
Brake Pad Material: Sintered metal
Brake Rotors: Tektro 180mm front and rear
Chain: 27
Chainstay: 18”
Crank Set: 46T, 170mm forged alloy, dual-sided aluminum bashguard
Crank Length: 170mm
Derailleur: 7-Speed Shimano Altus
Brake Calipers: Tektro Aries (MD-M300)
Brake Levers: Aluminum alloy comfort grip levers with motor cutoff switch and integrated bell
Bike Weight: 65lb
Payload capacity: 275lb
Standover Height: 17”
Total Length: 70”
Wheelbase: 44”
Dropout Width: 100mm Front, 135mm Rear
Bottom Bracket Shell Width: 68mm, square taper bottom bracket
Lights: Standard Rad Power Bikes LED headlight in front + Integrated tail light with brake light in rear
USB Port: 5V, 1 Amp (under display)
